Norcold N15DCSS

Norcold N15DCSS

Norcold N15DC 12V RV refrigerator
YOUR FRIDGE: NORCOLD N15DC (12V)

Everything for the Norcold N15DC

Fits every Norcold N15DC model: N15DCSS, N15DCMB, N15DCIMSS and N15DCIMMB (SS = stainless steel doors, MB = matte black doors, IM = ice maker). 15 cu. ft., 12V DC compressor, 63-5/16" × 32-3/4" × 24" cutout. Control boards, fan, thermistor and drawer hardware are shared with the N20DC.

✓ GUARANTEED FIT

Give us your model and serial number. If we say it fits and it doesn’t, we cover return shipping.

What’s wrong with your N15DC?

Norcold 640149 Thermistor & Cover ON light blinking fastThermistor & Cover 640149 →Fast blink = thermistor circuit. Check the plug at the board first. Norcold Guide 12V Power Check ON light blinking slow12V Power Check Guide →Slow blink = low or dirty 12V. A bad converter is the usual cause. Norcold 640178 Compressor Power Module Compressor won’t runCompressor Power Module 640178 →Fits every N15DC, regardless of serial number. Norcold 640964 User Interface Board Display or buttons not workingUser Interface Board 640964 →The front panel board. The top control board is 641043. Norcold 641042 Cabinet Fan Kit Uneven cooling, frost buildupCabinet Fan Kit 641042 →Circulates cold air through the cabinet. Norcold 641325 Fresh Food Door Gasket Door won’t seal or sweatsFresh Food Door Gasket 641325 →Fits both N15DC fresh food doors. Freezer gasket is 640982. Norcold 641586 Drawer Bracket & Rail Kit Freezer drawer binds or sits crookedDrawer Bracket & Rail Kit 641586 →Brackets, slides, rails, wheels and restraint in one kit. Norcold 640958 Door Sensor Magnet Light stays on / door alarmDoor Sensor Magnet 640958 →Tells the fridge whether the door is open or closed.

Parts that are specific to the N15DC:

Part N15DC
Power module 640178 (all serials)
Fresh food gasket 641325
Freezer gasket 640982

N15DC vs. N20DC

  N15DC N20DC
Size 15 cu. ft. 19 cu. ft.
Cutout 63-5/16" × 32-3/4" × 24" 69" × 36" × 24"
Doors, gaskets, bins, flapper N15DC-specific N20DC-specific
Control boards, fan, thermistor, drawer kit, handles Same Same

The model and serial number are on the label inside the fresh food compartment.

Repair guides for the N15DC

Before replacing a board: measure 12–13.5V DC at the fridge, then switch your meter to AC. More than 0.5V AC on the DC line points to a bad converter, not the fridge.
