Norcold N10DC 12V RV refrigerator
YOUR FRIDGE: NORCOLD N10DC (12V)

Everything for the Norcold N10DC

Fits N10DC, N10DCSS, N10DCSSR, N10DCSSL and N10DCBK. 10 cu. ft., 12V DC compressor, 59-7/8" × 23-1/2" × 24" cutout. Most parts are shared with the N8DC.

āœ“ GUARANTEED FIT

Give us your model and serial number. If we say it fits and it doesn’t, we cover return shipping.

What’s wrong with your N10DC?

Norcold 641592 Optical Control Board One side warm (freezer or fridge)Optical Control Board 641592 →The most common N8DC/N10DC fix. Test the thermistor first. Norcold 640149 Thermistor & Cover Temperatures off / not cooling rightThermistor & Cover 640149 →Test this first. It’s inexpensive and also fits the N15DC and N20DC. Norcold 640178 Compressor Power Module Compressor won’t runCompressor Power Module 640178 →Drives the 12V compressor. Check battery voltage and wiring first. Norcold 640103 Condenser Fan Weak cooling, runs hotCondenser Fan 640103 →The lower rear fan that carries heat away from the compressor. Norcold 640093 Evaporator Fan Condensation or uneven cooling insideEvaporator Fan 640093 →Moves cold air through the cabinet. Norcold 641545 Door Handle Broken door handleDoor Handle 641545 →Fits both doors. Replaces 640156 and 640160. Norcold 640158 Lower Door (N10DCSS) Damaged door or worn gasketLower Door (N10DCSS) 640158 →Comes with the gasket. Freezer door is 640153 (fits N8DCSS and N10DCSS).

Your serial number decides the control board:

Serial number Optical control board
Above SE079WDW00190 641592 (current)
Below SE079WDW00190 640338 (discontinued). Send us your serial.

N8DC vs. N10DC

  N8DC N10DC
Size 8 cu. ft. 10 cu. ft.
Cutout 52-7/8" × 23-1/2" × 24" 59-7/8" × 23-1/2" × 24"
Shelves Wire Glass
Lower door (SS) 640467 640158
Freezer door, boards, fans, thermistor Same Same

The model and serial number are on the label inside the fresh food compartment.

Repair guides for the N10DC

Before replacing a board: low battery voltage or undersized 12V wiring can make a compressor fridge act up. Check for at least 12V at the fridge while it’s running.
