Norcold Power Boards & Circuit Boards — Find the Right Board by Model

Need a Norcold power board? We stock every Norcold power board still in production, plus aftermarket replacement boards for older models no longer made by Norcold — including boards for the N7, N8, N10, N611, N811, N1095, 1200, 1210, 2118, and DC series. Use the model guide below to find the exact board for your refrigerator, or contact us with your model and serial number and we'll match it for you.

Where is the power board on a Norcold refrigerator?

The power board (also called the circuit board) is mounted behind the refrigerator, accessed from outside the RV. To reach it:

Remove the exterior access panel on your RV where the refrigerator vents.
Remove the board cover to expose the power board.
Before disconnecting anything, cut both AC power and battery (DC) power to the refrigerator.
Take a photo of the existing wiring layout before removing any wires — this makes reinstalling the new board fast and mistake-free.

Which Norcold Power Board Do I Need?

Find your refrigerator model below. For older models, the correct board depends on your unit's serial number, since Norcold updated board designs mid-production.

Model	Serial Number	Power Board
2118	All	Norcold 637082
1200	Below 8981138	Norcold 621271001 or Upgraded aftermarket 6212XX
1200	Above 8981138	Norcold 628661
1210	All	Norcold 628661 (OEM)
N611, N811	Below 9056491	Norcold 6212XX or Norcold 621991001
N611, N811	Above 9056491	Norcold 628661
N621, N821	Below 8970880	Norcold 6212XX
N621, N821	Above 8970880	Norcold 628661
N641, N841	Below 9044285	Norcold 6212XX
N641, N841	Above 9044285	Norcold 628661
NX641, NXA641, NX841, NXA841	All	Norcold 628661
N1095	Below 9044285	Norcold 6212XX
N1095	Above 9044285	Norcold 628661
N7, NA7, N7X, N7XF, N8, NA8, N8X, N8XF	All	Norcold 639593
N8DC, N8DCSS, N10DC, N10DCSS, N15DCSS, N20DC, N20DCSS, N2152, N2090, N2175	All	Norcold 640178
N4104, N4141, N4150	All	Norcold 692249

Not sure where to find your serial number? It's typically on a data plate inside the refrigerator compartment or on the back of the unit near the power board access panel.

Superseded / Discontinued Boards

If Norcold's original manual or a part you're replacing lists one of these part numbers, they have all been replaced by the 6212XX upgraded board:

Norcold 632168001
Norcold 621269001

Frequently Asked Questions

Do you carry every Norcold power board?
Yes. We stock every Norcold power board currently in production, plus aftermarket boards from Dinosaur Electronics for older Norcold models Norcold no longer supports.

How do I know which power board fits my Norcold refrigerator?
Match your refrigerator's model number and serial number to the table above. Many older models changed board design partway through production, so the serial number — not just the model — determines the correct board.

Is it safe to replace a Norcold power board myself?
Most RV owners can replace a power board themselves with basic tools. Always disconnect both AC and battery power before starting, and photograph the wiring before removing anything.

What if my part number isn't listed here?
Email us at info@rvfridgeguys.com or call 1-800-712-8822 with your model and serial number and we'll identify the correct board for you.
