Description
Dometic Americana II DM2872RB1 RV Refrigerator – 8 Cu. Ft. Class, 2-Door, 2-Way (AC/LP)
The Dometic Americana II DM2872 is the larger two-door, two-way absorption refrigerator in the Americana II line. It's sold as an 8 cu. ft. class refrigerator, with 7.31 cu. ft. of total storage measured to the AHAM standard. It runs on 120V AC shore power or LP gas, with 12V DC for the controls. It has a full steel surround frame, eye-level electronic controls with automatic LP ignition, and an LED interior light.
Key features
- Two-way power: automatic selection between 120V AC and LP gas
- Automatic electronic LP ignition
- LED fresh-food light: brighter and cooler-running than incandescent
- "Click Lock" handles that open in one motion and lock for travel
- Full steel surround frame with black trim
- Flexible storage: adjustable and removable shelves and door bins, two crispers, and door-shelf retainers for bottles
- Magnetic door seals. No frost limiter needed.
- Reversible hinges: ships right-hinged; doors open 180°
- Thermostat accessible behind the freezer door
- Accepts optional decorative door panels (sold separately)
Specifications
- Model: DM2872RB1
- Capacity: 8 cu. ft. class. AHAM-measured: 7.31 cu. ft. total (fresh food 5.6, freezer 1.7).
- Exterior dimensions: 60-13/16" H x 24-7/8" W x 26" D
- Cut-out (recess): approx. 59-15/16" H x 23-11/16" W x 24" D. Confirm against the Dometic installation manual before ordering.
- Net weight: 124 lbs
- AC power: 120V, 60 Hz, 2.7 A, 440 W
- DC power: 12V (controls)
- LP consumption: 1,500 BTU/hr at 11" water column
- Cooling: absorption (ammonia, R717), no compressor
- Hinge: right-hand, reversible
- Certification: CSA
Will it fit my RV?
Measure the height, width and depth of your current refrigerator opening and compare them with Dometic's installation manual. The DM2872 is the usual replacement for older Dometic 8 cu. ft. Americana models, such as the RM2852, DM2852 and DM2862, in openings of the same size. Make sure your roof or sidewall venting meets Dometic's installation requirements.
Why an absorption refrigerator?
Absorption refrigerators run silently on LP gas when you're off-grid, drawing only a small amount of 12V power for the controls. That's ideal for boondocking and dry camping.
Browse all new Dometic RV refrigerators.
Shop DM2872RB1 parts and accessories.
FAQ
Is the DM2872 7 or 8 cubic feet?
Dometic sells it as an 8 cu. ft. class refrigerator. Its AHAM-measured total capacity is 7.31 cu. ft.
Does it replace my RM2852 or DM2852?
In many RVs, yes. Compare your opening with the installation manual's cut-out dimensions to confirm.
Does it run on 12V DC alone?
No. It's a two-way model: 120V AC or LP gas. 12V DC powers the controls.
Do I need a technician?
No. With some help lifting it, most owners can install it themselves. If you're not comfortable with the gas and electrical connections, you can always hire a technician to come out. If you need help with the install, we're here for you. Just reach out.
